Installation
(continued)
Connect Your Equipment to the Surge Suppressor’s Phone Jacks (Optional Installation.
Available on Select Models Only): CONNECT A PHONE CABLE FROM THE WALL JACK DIRECTLY TO THE SURGE
SUPPRESSOR’S RJ-STYLE PHONE JACK LABELED “IN.” CONNECT A PHONE CABLE FROM THE SURGE SUPPRESSOR’S
RJ-STYLE PHONE JACK LABELED “OUT” DIRECTLY TO THE DEVICE TO BE PROTECTED. SELECT MODELS FEATURE TWO
“OUT” JACKS; EITHER ONE OR BOTH OF THE JACKS MAY BE USED, BUT PROTECTION IS FOR A DEVICE OR DEVICES
SHARING A SINGLE LINE ONLY. ALL MODELS WITH PHONE LINE SURGE PROTECTION, EXCEPT THE TLP810NET, PROTECT
DEVICES ON A SINGLE LINE ONLY. TLP810NET MODELS FEATURE A SINGLE SET OF RJ-STYLE PHONE JACKS WHICH
PROTECT DEVICES ON TWO LINES. THE SURGE SUPPRESSOR MUST ALWAYS BE THE FIRST ITEM CONNECTED IN LINE FROM
THE WALL JACK. THE SURGE SUPPRESSOR MUST BE PLUGGED INTO A 3-WIRE, GROUNDED AC OUTLET FOR PHONE LINE
SURGE PROTECTION TO WORK.
Connect Your Equipment to the Surge Suppressor’s Network Jacks* (Optional Installation.
Available on Select Models Only): CONNECT A DATA CORD FROM THE WALL JACK OR CABLE/DSL MODEM
DIRECTLY TO THE SURGE SUPPRESSOR’S NETWORK JACK LABELED “IN.” CONNECT A DATA CORD FROM THE SURGE
SUPPRESSOR’S NETWORK JACK LABELED “OUT” DIRECTLY TO THE DEVICE TO BE PROTECTED (TYPICALLY A COMPUTER’S
NETWORK INTERFACE CARD).
THE SURGE SUPPRESSOR MUST ALWAYS BE THE FIRST ITEM CONNECTED IN LINE FROM THE ETHERNET SOURCE
(TYPICALLY A WALL JACK). THE SURGE SUPPRESSOR MUST BE PLUGGED INTO A 3-WIRE GROUNDED AC OUTLET FOR
NETWORK LINE SURGE PROTECTION TO WORK.
Connect Your Equipment to the Surge Suppressor’s Coaxial Jacks (Optional Installation.
Available on Select Models Only): CONNECT A COAXIAL CABLE FROM THE WALL JACK DIRECTLY TO THE SURGE
SUPPRESSOR’S “F” STYLE COAXIAL JACK LABELED “IN.” CONNECT A COAXIAL CABLE FROM THE SURGE SUPPRESSOR’S
“F” STYLE COAXIAL JACK LABELED “OUT” DIRECTLY TO THE DEVICE TO BE PROTECTED. SELECT MODELS INCLUDE A
SECOND SET OF COAXIAL JACKS FOR SIMULTANEOUS CONNECTION AND PROTECTION OF DEVICES ON TWO SEPARATE LINES
(CABLE, ANTENNA OR SATELLITE). THE SURGE SUPPRESSOR MUST ALWAYS BE THE FIRST ITEM CONNECTED IN LINE FROM
THE COAXIAL WALL JACK. THE SURGE SUPPRESSOR MUST BE PLUGGED INTO A 3-WIRE GROUNDED AC OUTLET FOR
COAXIAL LINE SURGE PROTECTION TO WORK.
* 10/100 BaseT/TX, Token Ring. Not compatible with PoE (Power Over Ethernet) applications.
FCC Part 68 Notice (United States Only)
If your Modem/Fax Protection causes harm to the telephone network, the telephone company may temporarily discontinue your service. If possible,
they will notify you in advance. If advance notice isn't practical, you will be notified as soon as possible. You will be advised of your right to file a
complaint with the FCC. Your telephone company may make changes in its facilities, equipment, operations or procedures that could affect the
proper operation of your equipment. If it does, you will be given advance notice to give you an opportunity to maintain uninterrupted service. If you
experience trouble with this equipment's Modem/Fax Protection, please visit www.tripplite.com/support for repair/warranty information. The
telephone company may ask you to disconnect this equipment from the network until the problem has been corrected or you are sure the equipment
is not malfunctioning. There are no repairs that can be made by the customer to the Modem/Fax Protection. This equipment may not be used on
coin service provided by the telephone company. Connection to party lines is subject to state tariffs. (Contact your state public utility commission
or corporation commission for information.)
Lifetime Limited Warranty
Seller warrants this product, if used in accordance with all applicable instructions, to be free from original defects in material and workmanship
for its lifetime. If the product should prove defective in material or workmanship within that period, Seller will repair or replace the product, in its
sole discretion. Service under this Warranty can only be obtained by your delivering or shipping the product (with all shipping or delivery charges
prepaid) to: Tripp Lite, 1111 W. 35th St., Chicago, IL 60609. Seller will pay return shipping charges.
The warranties of all TRIPP LITE surge suppressors are null and void if they have been connected to the output of any UPS system. The warranties
of all TRIPP LITE UPS Systems are null and void if a surge suppressor has been connected to its output receptacles.
THIS WARRANTY DOES NOT APPLY TO NORMAL WEAR OR TO DAMAGE RESULTING FROM ACCIDENT, MISUSE, ABUSE OR NEGLECT. SELLER
MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY EXPRESSLY SET FORTH HEREIN. EXCEPT TO THE EXTENT PROHIBITED BY
APPLICABLE LAW, ALL IMPLIED WARRANTIES, INCLUDING ALL WARRANTIES OF MERCHANTABILITY OR FITNESS, ARE LIMITED IN DURATION
TO THE WARRANTY PERIOD SET FORTH ABOVE; AND THIS WARRANTY EXPRESSLY EXCLUDES ALL INCIDENTAL AND CONSEQUENTIAL
DAMAGES. (Some states do not allow limitations on how long an implied warranty lasts, and some states do not allow the exclusion or limitation
of incidental or consequential damages, so the above limitations or exclusions may not apply to you. This Warranty gives you specific legal rights,
and you may have other rights which vary from jurisdiction to jurisdiction.)
WARNING: The individual user should take care to determine prior to use whether this device is suitable, adequate or safe for the use intended.
Since individual applications are subject to great variation, the manufacturer makes no representation or warranty as to the suitability or fitness of
these devices for any specific application.
The policy of Tripp Lite is one of continuous improvement. Specifications are subject to change without notice.
3
201010194 93-2666.indd 3
11/12/2010 9:36:52 AM
